Universal Golf Cart Voltage Reducer Converter 36V/48V to 12V 30A 350W, DC Transformer for Yamaha

Golf Cart Voltage Converter Regulator DC 36V 48V to DC 12V 30A 350W, input voltage range is DC 30-60V, 6-pin plug

Universal fit for Club Car, EZGO, Yamaha and other golf carts

Connects entire battery pack instead of just one battery which improves the life of the battery pack

5 Safty Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage; stable and reliable performance

The Industry grade DC converter is widely used in golf cart, forklifts, bus, large trucks, motor, solar generate electricity, display screen of bus and taxi, car audio device, LED, intercom and monitor system, etc.
Universal Golf Cart Voltage Reducer Converter 36V/48V to 12V 30A 350W, DC Transformer for EZGO Club Car Yamaha
Wire Descriptions
Yellow – 30-55V Battery Input (+)
Black – 30-55V Battery Input (-)
Green – Key Switch “NO” position
Red – 12V Output(+)
Blue – 12V Output(-)
Applications: golf cart, forklifts, bus, large trucks, motor car, solar power generating, bus displaying screen, taxi advertising screen, taxi radio without interference, car audio speaker, LCD TV, LED, intercom and monitor system, etc.
Specifications:
Case material: die-cast aluminum
Potting material: epoxy sealed
Efficiency:96%max
Input Voltage: 30-55V DC
Output Voltage:12V DC
Output Current :10A
Output Rated Power: 350W
Line Regulation: 0.2%
Load Regulation :0.2%
Voltage Accuracy :1.5%
Operating Temperature:-30~70C
Certificates:CE
Package Included:
1 x DC Voltage Converter Regulator
