100% NEW and Made with the Highest Quality Components Available
Full One Year Warranty
Computer tested for consistent Quality and unsurpassed reliability
– Voltage: 12V Amperage: 22 Amps Rotation: Reversible Source: Aftermarket
Replaces Part Numbers: GSB107-02 10-81100-10-00 10811001000 J10811001000 GSB10702
RAREELECTRICAL BRAND COMPATIBLE WITH HITACHI, YAMAHA
HITACHI GSB107-02
YAMAHA 10-81100-10-00, J10-81100-10-00
UNIT TYPE: YAMAHA, HITACHI
VOLTAGE: 12
AMPERAGE 22
ROTATION: REVERSIBLE
FIELD HSG OD: 113MM / 4.449IN
OVERALL LENGTH: 246MM / 9.685IN
SHAFT OD: 17MM / 0.669IN
SHAFT NOTES: WITH KEYWAY
TERMINAL 1 SIZE: M6-1.0
TERMINAL 2 SIZE: M6-1.0
TERMINAL 3 SIZE: M6-1.0
TERMINAL 4 SIZE: M6-1.0
WEIGHT: 18.1 LBS / 8.23 KG
NOTES:
INCLUDES HARNESS WITH 2 BULLET TERMINALS(4 TERMINAL 2 WIRE)
APPLICATIONS
PLEASE VERIFY YOUR OEM PART NUMBER FROM YOUR UNIT TO ENSURE FITMENT.
1978-88 YAMAHA G1 GOLF CARTS W2-CYCLE ENGINES W2-CYCLE
