HOUR METER—-Contains hour meter, 2 resettable job (TMR1/TMR2) timer;Help you track how many hours you put on your machine ;External 5-277 Volt AC/DC power. AC/DC voltage compatible . Allows user to preset total hours and replace a failed meter without loss of total elapsed time.
TOTAL HOURS—-Display shows total run time of machine and remains visible.TOT hours are non-resettable; Read up to 999,999 hours ; 0.1 hour accuracy;The initial hour reading can be set repeatedly within 1 hour to replace an old hour meter.
JOB TIMER—-JOB timer used to measure the time of a particular work job, Like change oil, Air filter Replacement etc…;Includes 2 resettable JOB timers:TMR1 & TMR2 ;Read up to 999,999 hours ; 0.1 hour accuracy;
DATA STORAGE &INSTALLATION —- Automatic data storage when external power is off ; Built-in CR2050 battery keeps recorded data consistently visible ; Easy to install ; Snap-in design and fits standard panel cut-out; Panel Cutout Size:Approx 37.5 24.5mm(1.5 1 Inch).
OTHER —- Sealed with epoxy resin for excellent heat and vibration resistance ; Waterproof rating: IP68; Contains detailed instructions for use ; CE ROHS certification;2-year warranty
RL-HM038AD Digital LCD Hour Meter contains hour meter, 2 resettable job timer. This hour meter Initial hour reading can be set to replace an old hour meter. Applicable voltage: AC/DC 5V to 277V , Easy to install , Snap-in design and fits standard panel cut-out . Waterproof design.
Product Features:
1 Hour Meter (TOT) Features—- Help you track how many hours you put on your machine.
Display shows total run time of engine and remains visible.Total Hours reading displays from 0 to 999,999 Hours, 0.1 hour accuracy.TOT hours are non-resettable.The initial hour reading can be set repeatedly within 1 hour to replace an old hour meter.
2 JOB timer (TMR1 & TMR2 ) Features—- Used to measure the time of a particular work job, Like change oil
By operating the button display shows job run time of machine and remains visible.JOB timer (TMR1 & TMR2 ) reading displays from 0 to 999,999 Hours, 0.1 hour accuracyJOB timer (TMR1 & TMR2 ) is resettable.
3 Other Features
Internal CR2050 battery , Battery life is up to 6 years, Data retained up to 25+ yearsLCD Screen size 12.5mm 25mmEasy to install, including metallic sheaths sheaths Instruction manualCE ROHS certificationWaterproof rating: IP68.
4 Applications:
This hour meter suitable for Outdoor Power Equipment Generators Agriculture Construction Machinery Vehicles Boats etc… such as:Lawn Mower Garden Tractor Riding mower Leaf Blower Pressure washer chainsaw Snowblower Brush Mower Line Trimmer string trimmer Pressure Washer Portable inverter generator Motorcycle Dirtbike ATV UTV Scooter Paramotor Harley dual-sport bike Golf cart Outboard Jetski Pontoon boat Mercury Raceboat Hovercraft etc…
