DC to DC Voltage Reducer Step Down Waterproof Voltage Regulator Buck Converter for Golf Cart Club Car (48V to 12V 10A)

Input Voltage: 48V nominal, Input range: 40V to 60V ; Output Voltage: DC 12V 10A 120W High conversion efficiency, Maximum Efficiency: 95%; Ripple Wave: 50Mv; Starting delay time: 2S Over-current /Over-load /Low-load /Short-circuit /Over-heat intelligent protection Compact aluminium shell with epoxy potting, 100% waterproof, anti-dust, anti-shock protection and better heat dissipation Widely used to golf cart, motor, speaker, GPS, LED car display screen, air-conditioner, electric fan, solar energy, photo-voltaic power, DVD, industrial equipment ect.
Product Description
Specification: Input Voltage: 48V nominal Input range: 40V to 60V Input Current: 10A (max) No-load input current: 10mA Output Voltage: DC 12V 2% Output Current: 10A Ripple Wave: 50Mv Starting Delay time: 2S Maximum Efficiency: 95% Size: 75mm x75mm x 32mm Net Weight: 248g / 8.75oz Features: All epoxy sealed containers with waterproof die-cast aluminum housing; Light compact, convenient to use and transport; Non-isolated; Operating temperature: -10 ~ +60 (max: +80 ); With overload / over-current / over / low voltage protection, stable performance; Auto recovery. Warning Please install the wiring correctly, otherwise it may damage the product and burn the fuse. Package including: 1x Voltage Reducer Converter 48V to 12V 10A 120W
