Golf Cart Brake Drum for TXT 1982-up Electric Vehicles and 1982-1993 2-Cycle Gas Vehicles.
OEM part# 19186G1P. Warm tips: Hub spline and Rear Axle Shaft Spline should be matched tight. When one of them worn out, both of them should be replaced at the same time. Otherwise the hub spline will strip soon.
Easy to disassemble. This is for the brake drum only. When replacing this brake drum, check the Hub assembly as well. This Brake hub/drum is a replacement for the earlier hub & drum and has the star spline instead of the straight key.
2 PCS brake drum. There is a 3/4-Inch center hole with a 24-tooth star spline The hub is held in place by a castellated nut (5/8-Inch x 18tpi) and a thick (118-Inch) flat washer.
