Part Number Replace for 101908701 102774701 1019087-01 1027747-01 Albright SW80-2028P
Application Compatible with Club Car 95-Up DS and 2004-2008 Precedent Golf Carts
Spec 48V 4 Terminal Solenoid Silver Contacts Continuous Duty
Note Take care not to overtighten the nut/terminal during installation.You’d better often check the nuts as they may become loose over time.
1 Year Warranty Please feel free to contact us for any questions, we will give quick response asap.
Included
solenoid and resistor assembly
Spec
Voltage: 48V
Terminals: 4
Duty Continuous
High Current Stud: Around 5/16 Inch
Low Current Stud 4.7mm Spade and 6.4mm Spade
Mounting Type: Flat 180
Contacts Material: Red Copper
Housing Material: PMC
Body Shell Plating: Zinc Plating
Potted coil: Copper
Resistance: 181
Work Current: 200A
Inrush Current: 240A
Application
Replace for 101908701 102774701 1019087-01 1027747-01 Albright SW80-2028P
Application
Compatible with Club Car 95-Up DS and 2004-2008 Precedent Golf Carts
