36 Volt Continuous Duty Solenoid Relay for EZGO Electric Golf Cart, 70 Series OEM# 27855G01 11761G1 27855G02 31680G1 3016

Replaces Part #’s: 70-120224, 3016, 11761-G1, 27855-G01, 27855-G02, 31680-G1, Cole Hersee 24080, E-Z-Go 11761GA

1980-2010 Electric Golf Cart, Voltage 36 Volt, 4 terminal Heavy-duty Solenoid with Copper Contacts, Flat Mounting Bracket/ Apply For Marathon EZGO TXT Series

Resistance is 18| , Max Transient current can be 200A, but Continuous Working Current recommend 80amp/ Dimensions: 2) 5/16-24 Contact Terms/ 2) 10-32 Terminal/ Mounting holes: 5/16 x 19/32, 2-13/64 on centers

Acts as the conduit between the golf car battery and starter generator, Copper alloy contact terminals Insulated base with steel housing

Make sure your small diode is in the correct direction with the line pointing to the positive side.
Product Description
EZGO Electric 36 Volt Continuous Duty Solenoid Golf Car Relay #70 Series Relay Replaces E-Z-Go Electric Golf Cart 27855G01, 11761G1, 27855G02, 31680G1, 3016
